Products / Ball Valves / Yellow Ball Valve
Code DO-BV – Size ½"–4"
Full-flow ball valve, nickel-plated brass body, red lever handle, yellow body finish.
| Code | Size | A (mm) | B (mm) | C (mm) | D (mm) |
|---|---|---|---|---|---|
| DO-BV-101 | ½" | 56 | 48 | 103 | 14 |
| DO-BV-102 | ¾" | 60 | 55 | 103 | 18 |
| DO-BV-103 | 1" | 71 | 62 | 126 | 23 |
| DO-BV-104 | 1¼" | 78 | 72 | 160 | 30 |
| DO-BV-105 | 1½" | 94 | 83 | 168 | 35 |
| DO-BV-106 | 2" | 105 | 88 | 188 | 42 |
| DO-BV-107 | 3" | 148 | 125 | 260 | 64 |
| DO-BV-108 | 4" | 173 | 137 | 275 | 78 |
| Component | Material |
|---|---|
| Body | Brass |
| Cover | Brass |
| Seal | PTFE |
| Ball | Brass |
| Sleeve | PTFE |
| Stem | Brass |
| Nut | Gal. Brass |
| Handle | Brass |
HeatingCoolingSteamCompressed Air
| Code | Size |
|---|---|
| DO-BV-101 | ½" |
| DO-BV-102 | ¾" |
| DO-BV-103 | 1" |
| DO-BV-104 | 1¼" |
| DO-BV-105 | 1½" |
| DO-BV-106 | 2" |
| DO-BV-107 | 3" |
| DO-BV-108 | 4" |
| Item | Value |
|---|---|
| Guarantee | 5 years |
| WRAS | Not listed |
Install in accordance with the Installation Guide provided in the Documentation tab and to ISO228 threading practice. Isolate the line, verify all connections, and pressure-test before commissioning. Contact our technical team for project-specific guidance.
